Overview
The Fluke 1650 series of testers verify the safety of electrical installations in domestic, commercial and industrial applications. They ensure that fixed wiring is safe and correctly installed to meet the requirements of the Wiring Regulations / Part P of the Building Regulations. The unique ergonomic design, low weight, and padded neck-strap to free your hands, makes operating easy to undertake.
Features
- Advanced and patented loop measurement technology prevents RCD tripping and guarantees consistent readings after multiple tests
- Simultaneous read-out with loop impedance
- Test wide range of RCDs
- Test phase sequence rapidly on three phase systems
- Dual display gives simultaneous readout of mains voltage and frequency
- Insulation test voltages of 250, 500 and 1000 V to cover most applications. 50V and 100V capabilities on the 1653B and 1654B versions
- Time-saving 'auto-null' feature subtracts lead resistance from measurements
- Clear indication of applied voltage
- Three-wire tests for accurate measurement
- Wiring connection check indication and live circuit detection for added safety
- Easy: simply turn the knob, press the button and see the results
- 1 A resolution on measurements
- 0.01 .W resolution on loop measurements
- Auto-null to remove test-lead resistance from measurement
- Efficient: measure loop impedance without tripping RCDs, eliminating the need to bypass them
- High-resolution measurements down to 0.01 .W
- User selectable safety voltage level of 50 or 25 V
- Auto discharge allows fast and safe discharge of electrical energy in capacitive circuits
- Added safety through live circuit detection, to check and inhibit test if circuit under test is live
- Rugged: with stands a one-meter drop for demanding field use
- RCD Tripping Current Test (ramp test)
- Wiring connection check indication for added safety
- Safe: slim probe with test button keeps your eyes on the panel while probing hard to reach points
- Phase selector switch
- Comfortable: compact and lightweight (less than 1.2 kg)
- Memory interface (1653B and 1654B models only).
Technical
Important note
The Instrument Solutions hire models are the 1652C versions of this product which have a phase rotation capability. If this model is not available we also rent the 1664 FC version which is a similar product which includes additional features such as downloading of data via a App.
