Simultaneously portable and benchtop multimeter, the ASYC IV models are simple and intuitive to use. Accessible directly, the various measurements are represented explicitly in the form of pictograms on the electronic switch.
The display allows users to view the measurement results either as numeric values or as graphs showing the trend over time. Recorded measurements can be displayed as traces, with the possibility of positioning cursors and zooming on a part of the recorded curve.
An integrated help function available in French and English provides information on the measurements in progress.
USB or BT communication is provided to transfer the data onto a PC for saving and programming with the LV/LW drivers. Once the instrument is connected to the PC, the firmware can be updated by accessing the "Loader" program on the web.
NOTE: Non-Bluetooth version available please contact the sales team for pricing.
- Optimized display: Graphical display of trends and multiple parameters, 600 Hz waveform
- Storage of up to 30,000 measurements with direct access [Menu]
- Power supply via USB charger
- Top-of-the range specifications: 100 kcts, 200 kHz bandwidth and 0.02% accuracy
- Multiple analytical tools: time/date stamped monitoring of Min/Max/Avg and Peak, filtering, duty cycle
DC, AC and AC+DC voltages TRMS
Range 100 mV */ 1000 mV / 10 V / 100 V / 1000 V
Resolution 1 μV / 10 μV / 0.1 mV / 1 mV / 10 mV
AC and AC+DC bandwidth 200 kHz
DC accuracy 0.02%
AC and AC+DC (VLowZ) accuracy 0.3%
DC, AC and AC + DC TRMS current
Range 1000 μA / 10 mA / 100 mA / 1000 mA / 10 A / 20 A (30s max on 100 A range)
Resolution 10 nA / 0.1 μA / 1 μA / 10 μA / 100 μA / 1000 μA
DC / AC and AC+DC accuracy 0.08%/0.3%
AC and AC+DC bandwidth 50 kHz
Frequency range 10 Hz / 100 Hz / 1 kHz / 10 kHz / 100 kHz / 1 MHz / 5 MHz
Resolution 0.0001 Hz / 0.001 Hz / 0.01 Hz / 0.1 Hz / 1 Hz / 10 Hz / 100 Hz
Resistance and continuity
Ranges 100 Ω */ 1 kΩ / 100 kΩ / 1000 KΩ / 10 MΩ / 100 MΩ
Resolution 0.001 Ω / 10 mΩ / 100 kΩ / 10Ω / 10Ω / 1 kΩ
Basic accuracy 0.07%
Protection 1000 V electronic protection
Audible continuity detection 1000 Ω / SIGNAL <20 Ω < 3.5 V
Threshold voltage measurement Diode 0 -2.6 V <1 mA + Zener diode or LED 0-2.6 V <11 mA
Ranges 1 nF / 10 nF / 100 nF / 1000 nF / 10 μF / 100 μF / 1 mF / 10 mF
Resolution* 1 pF / 10 pF / 0.1 nF / 1 nF / 0.01 μF / 0.1 μF / 1 μF / 10 μF
Temperature with Pt100/1000 and K/J thermocouples
Operating range -200 °C to +800° C with Pt and -40 to +1200 °C with K thermocouple
Accuracy 0.1 %
Other Measurement functions
SURV MAX/MIN/AVG Time/date-stamped on all the main positions
REL Reference-delta relative value on 3 displays + main measurement
PWM filter 4th order 300 Hz low-pass filter for measurements on variable speed drives of asynchronous motors
SPEC Display of the measurement tolerance + Smin + Smax
GRAPH Trends of main measurements with max., variable time and display of waveform (50/60 and 600 Hz)
Secondary measurements 3 measurements + main measurement
Measurement storage 30,000
The ASYC IV models are equipped with a universal communication mode, based on the SCPI standard, via USB or Bluetooth. The SX-DMM software is a simple, effective tool for display, processing and analysis of the data. SX-DMM is delivered as standard with the product and updates are available to download free of charge from the Support website. The SX-DMM software can be used for real-time processing of the data on a PC, upgrading of the instrument and calibration, as well as offering a new function for automatic adjustment of the time on the instrument. It is also possible to display the storage capacity.
The ANDROID application, available for download from the Google store, can be used to monitor measurement campaigns and view the measurements remotely.
