Available in three versions the Testo 835 range of infrared thermometers are ideal for measuring temperatures at a distance due to them having 50:1 optics (5 m distance = 10 cm measurement spot diameter). All units also have a 4 point laser which shows the exact measuring position and values can be saved in the internal memory for subsequent analysis on the PC.
Features
The 835-T1 model has a measuring range of -30 to +600 oC which makes it ideal for monitoring wall temperature, troubleshooting in heating and air conditioning systems, or the quality control of industrially manufactured products.
The 835-T2 has an extended measuring range of -10 to +1500 oC which is suited to measuring temperature in the glass, ceramics and metal industries.
The 835-H1 has an integrated surface moisture measurement capability making this product ideal for detecting the risk of mould in building fabrics.
- Measure temperatures safely and accurately even at long distances
- No measurement errors, thanks to focused optics (5 m distance = 10 cm measurement spot)
- Convenient menu guidance with icons and joystick
- Save measurement data on-site and subsequently analyse it via PC
Technical
Display Dot matrix
Storage temperature -30 to +50 °C
Operating temperature -20 to +50 °C
Weight 527 g
Dimensions 193 x 166 x 63 mm
Testo 835-T1 model
Temperature measuring range -30 to +600 °C
Temperature accuracy ±2.5 °C (-30.0 to -20.1 °C ), ±1.5 °C (-20.0 to -0.1 °C ), ±1.0 °C (+0.0 to +99.9 °C ), ±1 % of mv (remaining range)
Temperature resolution 0.1 °C
Testo 835-T2 model
Temperature measuring range -10 to +1500 °C
Temperature accuracy ±2.0 °C or ±1 % of mv
Temperature resolution 0.1 °C (-10.0 to +999.9 °C ), 1 °C (+1000.0 to +1500.0 °C)
Testo 835-H1 model
Temperature measuring range -30 to +600 °C
Temperature accuracy ±2.5°C (-30.0 to -20.1 °C ), ±1.5°C (-20.0 to -0.1 °C ), ±1.0°C (+0.0 to +99.9 °C ), ±1 % of mv (remaining range)
Temperature resolution 0.1 °C
Temperature measuring range -30 to +600 °C
Humidity measuring range 0 to 100 %rh
Humidity accuracy ±2 %rh, ±0.5 °C
Humidity resolution 0.1 °C, 0.1 %rh, 0.1 °Ctd
All models (optional probes)
Type K accuracy ±(-0.5 °C +0.5 % of mv)
Type K resolution 0.1 °C
